iOS File Provider Extension Tutorial

In this tutorial, you will learn about the File Provider framework and how to implement your own File Provider extension to expose your app’s own content.

5/5 3 Ratings · Leave a Rating

Version

  • Swift 5, iOS 12, Xcode 10

First introduced in iOS 11, a File Provider extension provides access to content managed by your app via the iOS Files app. Additionally, other apps can access your app’s data by using either the UIDocumentBrowserViewController or UIDocumentPickerViewController classes.

The main tasks of a File Provider extension are to:

  • Create file placeholders that represent the remote content.
  • Intercept reads from the host app so that the documents can download or update.
  • Fire a notification after an update to a document occurs so that the changes can upload to the remote server.
  • Enumerate the stored documents and directories.
  • Perform actions on a document such as renaming, moving, or deleting.

You’ll use a Heroku Button to configure the server that hosts your files. Once the server setup completes, you’ll configure the extension to enumerate the contents of the server.

Getting Started

To get started, click the Download Materials button at the top or bottom of this tutorial. In the downloaded folder, navigate into the Favart-Starter folder and open Favart.xcodeproj in Xcode. Make sure you’ve selected the Favart scheme, then build and run the app, and you’ll see the following:

The container app for your File Provider.

The app presents a basic view that educates the user about how to enable the File Provider extension since you won’t actually be doing anything within the app itself. Each time you build and run the app in this tutorial, you’ll then return to the home screen and open the Files app to access your extension.

Note: If you want to run the sample project on a real device, in addition to setting a development team for both targets, you must edit Favart.xcconfig inside the Configuration folder. Update the bundle identifier to a unique value.

The sample project uses this value for the PRODUCT_BUNDLE_IDENTIFIER build setting in both targets as well as the App Group identifier in Provider.entitlements and the associated NSExtensionFileProviderDocumentGroup value in Info.plist. If you don’t keep the values updated consistently in the project, you might see obscure and hard to debug errors. Using custom build settings is a great way to keep things running smoothly.

The sample project includes the basic components that you’ll use for your File Provider extension:

  • NetworkClient.swift contains a network client for talking to the Heroku server.
  • FileProviderExtension.swift has the File Provider extension itself.
  • FileProviderEnumerator.swift contains the enumerator, which is used to list the contents of a directory.
  • Models is a group that contains the models needed to complete the extension.

Setting Up the Back End With Heroku

To get started, you’ll need your own instance of the back end server. Fortunately, this is easy with a Heroku Button. Click the button below to access the Heroku dashboard.

Deploy

After you either sign up for a free account or sign in to Heroku, you’ll end up on a page similar to the following.

Deploy to Heroku

On this page, there is an option to name your application. You may choose a name, or Heroku will generate a name for you if you leave the field blank. Since there are no other configurations to worry about, click the Deploy app button and after a few moments, your back end will be up and running.

Deploy successful

Once Heroku finishes deploying the application, click the View button at the bottom. This will take you to the URL that hosts your instance of the back end. At the root of the application, you should see a JSON message reading the familiar Hello world!.

Finally, you need to copy the URL of your Heroku instance. You only want the domain portion, which should look like this: {app-name}.herokuapp.com.

In the starter project, open Provider/NetworkClient.swift. Towards the top of the file, you should see a warning telling you to Add your Heroku URL here. Remove the warning and replace the components.host placeholder string with your URL.

That completes the server configuration. Next, you’ll define the model which the File Provider relies on.

Defining an NSFileProviderItem

First, the File Provider needs a model that conforms to NSFileProviderItem. This model will provide information about files managed by the File Provider. The starter project contains FileProviderItem in FileProviderItem.swift you’ll use for this, but it requires a bit of work before you conform to the protocol.

While this protocol has twenty seven properties, only four are required. The optional properties provide the File Provider framework with more detailed information about each file and enable other capabilities. For this tutorial, you’ll focus on the required properties: itemIdentifier, parentItemIdentifier, filename and typeIdentifier.

itemIdentifier provides a uniquely identifiable key for the model. The File Provider uses parentIdentifier to keep track of its place in the extension’s hierarchy.

filename is the item’s name as displayed in the Files/em> app<. finally>typeIdentifier is the uniform type identifier, or UTI, for the item.

Before FileProviderItem can conform to NSFileProviderItem, it needs a way to work with the data coming from the back end. MediaItem defines a simple model that returns from the back end. Instead of using this model directly inside FileProviderItem, MediaItemReference will handle some additional logic for the extension to bridge the gap.

You’ll use MediaItemReference in this tutorial for two reasons:

  1. The back end hosted on Heroku is simple. It can’t provide all of the information required by NSFileProviderItem so you need to get it elsewhere.
  2. The File Provider extension is also going to be simple. A more complete File Provider extension would need to persist the information returned by the back end locally, using something like Core Data, in order to refer to it later in the extension’s lifecycle.

    To keep the focus of the tutorial on the File Provider extension itself, you’ll use MediaItemReference to cheat by embedding the data for the four required properties into a URL object. You’ll then base64-encode that URL into a NSFileProviderItemIdentifier. You won’t need to persist anything yourself because NSFileProviderExtension will handle it for you.

To start constructing the model open Provider/MediaItemReference.swift and add the following in MediaItemReference:

// 1
private let urlRepresentation: URL

// 2
private var isRoot: Bool {
  return urlRepresentation.path == "/"
}

// 3
private init(urlRepresentation: URL) {
  self.urlRepresentation = urlRepresentation
}

// 4
init(path: String, filename: String) {
  let isDirectory = filename.components(separatedBy: ".").count == 1
  let pathComponents = path.components(separatedBy: "/").filter {
    !$0.isEmpty
  } + [filename]

  var absolutePath = "/" + pathComponents.joined(separator: "/")
  if isDirectory {
    absolutePath.append("/")
  }
  absolutePath = absolutePath.addingPercentEncoding(
    withAllowedCharacters: .urlPathAllowed
  ) ?? absolutePath

  self.init(urlRepresentation: URL(string: "itemReference://\(absolutePath)")!)
}

Here’s what you did:

  1. For this tutorial, a URL will represent most of the information needed for the NSFileProviderItem.
  2. This computed property determines if the current item is the root of the file system.
  3. You made this initializer private to prevent usage from outside the model.
  4. You’ll use this initializer when reading the data from the back end. You assume that if the filename doesn’t contain a period it must be a directory, since the initializer can’t infer its type.

Before adding the final initializer, replace the import statement at the top of the file with the following:

import FileProvider

Next, add the following initializer below the previous code:

init?(itemIdentifier: NSFileProviderItemIdentifier) {
  guard itemIdentifier != .rootContainer else {
    self.init(urlRepresentation: URL(string: "itemReference:///")!)
    return
  }

  guard
    let data = Data(base64Encoded: itemIdentifier.rawValue),
    let url = URL(dataRepresentation: data, relativeTo: nil)
    else {
      return nil
  }

  self.init(urlRepresentation: url)
}

Most of the extension will use this initializer. Take note of the scheme itemReference://. You handle the root container identifier separately to ensure its URL path is properly set.

For the other items, the URL representation is retrieved by converting the raw value of the identifier to base64-encoded data. The information in the URL comes from the network request that first enumerated the instance.

Now that the initializers are out of the way, it’s time to add some properties to this model. First, add the following import at the top of the file:

import MobileCoreServices

This provides access to file types. Next, add the following at the end of the struct:

// 1
var itemIdentifier: NSFileProviderItemIdentifier {
  if isRoot {
    return .rootContainer
  } else {
    return NSFileProviderItemIdentifier(
      rawValue: urlRepresentation.dataRepresentation.base64EncodedString()
    )
  }
}

var isDirectory: Bool {
  return urlRepresentation.hasDirectoryPath
}

var path: String {
  return urlRepresentation.path
}

var containingDirectory: String {
  return urlRepresentation.deletingLastPathComponent().path
}

var filename: String {
  return urlRepresentation.lastPathComponent
}

// 2
var typeIdentifier: String {
  guard !isDirectory else {
    return kUTTypeFolder as String
  }

  let pathExtension = urlRepresentation.pathExtension
  let unmanaged = UTTypeCreatePreferredIdentifierForTag(
    kUTTagClassFilenameExtension,
    pathExtension as CFString,
    nil
  )
  let retained = unmanaged?.takeRetainedValue()

  return (retained as String?) ?? ""
}

// 3
var parentReference: MediaItemReference? {
  guard !isRoot else {
    return nil
  }
  return MediaItemReference(
    urlRepresentation: urlRepresentation.deletingLastPathComponent()
  )
}

Keep in mind:

  1. itemIdentifier must be unique per item managed by the FileProvider. If the item reference is the root, then it uses NSFileProviderItemIdentifier.rootContainer. If not, it creates an identifier from the reference’s URL.
  2. Here it creates an identifier based on the path extension of the URL. The odd looking UTTypeCreatePreferredIdentifierForTag is a C function that returns a UTI type for a given input.
  3. When working in a directory structure, it’s useful to reference the parent. This represents the folder that contains the current reference. It’s optional because the root reference doesn’t have a parent.

You added a few additional properties here that don’t require much explanation but will be useful when creating a NSFileProviderItem. With that, the reference model is complete. It’s time to hook everything up in FileProviderItem.

Open FileProviderItem.swift and add the following at the top of the file:

import FileProvider

Then, add the following to the bottom of the file, outside the class implementation:

// MARK: - NSFileProviderItem

extension FileProviderItem: NSFileProviderItem {
  // 1
  var itemIdentifier: NSFileProviderItemIdentifier {
    return reference.itemIdentifier
  }

  var parentItemIdentifier: NSFileProviderItemIdentifier {
    return reference.parentReference?.itemIdentifier ?? itemIdentifier
  }

  var filename: String {
    return reference.filename
  }

  var typeIdentifier: String {
    return reference.typeIdentifier
  }

  // 2
  var capabilities: NSFileProviderItemCapabilities {
    if reference.isDirectory {
      return [.allowsReading, .allowsContentEnumerating]
    } else {
      return [.allowsReading]
    }
  }

  // 3
  var documentSize: NSNumber? {
    return nil
  }
}

FileProviderItem now conforms to NSFileProviderItem and implements all required properties. Going through the code:

  1. Most of the required properties simply map over logic you previously added to MediaItemReference.
  2. NSFileProviderItemCapabilities indicates what actions can be taken on the item in the document browser – such as reading and deleting. For this app, you only need to allow reading and enumerating directories. In a real-world use case, you’d likely use the .allowsAll capability since a user would expect all actions to work.
  3. This tutorial won’t use the document size, but it’s included to prevent a crash in NSFileProviderManager.writePlaceholder(at:withMetadata:). This is likely a bug with the framework, and fortunately, a typical app’s File Extension would provide a documentSize anyway.

That’s it for the model. NSFileProviderItem has more properties, but what you’ve implemented will suffice for this tutorial.

Enumerating Documents

Now that the model is in place, it’s time to put it to use. To display the items defined by the model to the user, you need to tell the system about your app’s content.

NSFileProviderEnumerator defines the relationship between the system and the app’s content. In a bit, you’ll see how the system requests an enumerator by providing an NSFileProviderItemIdentifier which represents the current context. If the user is viewing the root of your extension, the system will supply the .rootContainer identifier. When the user navigates inside a directory, the system then passes in the identifier for that item defined by your model.

First, you’ll build out the enumerator provided in the starter. Open Provider/FileProviderEnumerator.swift and add the following below path:

private var currentTask: URLSessionTask?

This property will store a reference to the current network task. This provides the ability to cancel the request.

Next, replace the contents of enumerateItems(for:startingAt:) with the following:

let task = NetworkClient.shared.getMediaItems(atPath: path) { results, error in
  guard let results = results else {
    let error = error ?? FileProviderError.noContentFromServer
    observer.finishEnumeratingWithError(error)
    return
  }

  let items = results.map { mediaItem -> FileProviderItem in
    let ref = MediaItemReference(path: self.path, filename: mediaItem.name)
    return FileProviderItem(reference: ref)
  }

  observer.didEnumerate(items)
  observer.finishEnumerating(upTo: nil)
}

currentTask = task

Here, the provided network client code fetches all the items at a specified path. Upon a successful request, the enumerator’s observer returns new data by calling didEnumerate followed by finishEnumerating(upTo:) to indicate the end of the batch of items. It notifies the enumerator’s observer if an error occurs from the request by calling finishEnumeratingWithError.

Note: A production application might use pagination to fetch data. It would use the NSFileProviderPage method parameter to do this. In this scenario, an application would use integers as page indices which would then get serialized and stored in the NSFileProviderPage struct.

The last step in completing the enumerator is to add the following to invalidate():

currentTask?.cancel()
currentTask = nil

This will cancel the current network request if needed. It’s always a good idea to be conscious of resource use on a user’s device, such as networking or location access.

With that method complete, it’s time to use this enumerator to access data stored in the back end. The remainder of the app’s logic will go inside your FileProviderExtension class.

Open Provider/FileProviderExtension.swift and replace the contents of item(for:) with the following:

guard let reference = MediaItemReference(itemIdentifier: identifier) else {
  throw NSError.fileProviderErrorForNonExistentItem(withIdentifier: identifier)
}
return FileProviderItem(reference: reference)

The system provides the identifier passed to this method, and you return a FileProviderItem for that identifier. The guard statement ensures the identifier creates a valid MediaItemReference.

Next, replace urlForItem(withPersistentIdentifier:) and persistentIdentifierForItem(at:) with the following:

// 1
override func urlForItem(withPersistentIdentifier
  identifier: NSFileProviderItemIdentifier) -> URL? {
  guard let item = try? item(for: identifier) else {
    return nil
  }

  return NSFileProviderManager.default.documentStorageURL
    .appendingPathComponent(identifier.rawValue, isDirectory: true)
    .appendingPathComponent(item.filename)
}

// 2
override func persistentIdentifierForItem(at url: URL) -> NSFileProviderItemIdentifier? {
  let identifier = url.deletingLastPathComponent().lastPathComponent
  return NSFileProviderItemIdentifier(identifier)
}

Going over this:

  1. You validate the item to ensure that the given identifier resolves to an instance of the extension’s model. You then return a file URL specifying where to store the item within the file manager’s document storage directory.
  2. Each URL returned by urlForItem(withPersistentIdentifier:) needs to map back to the NSFileProviderItemIdentifier it was originally set out to represent. In that method, you built the URL in the format <documentStorageURL>/<itemIdentifier>/<filename>, so here you will take the second to last path component as the item identifier.

There are two methods coming up that require you to reference a file placeholder URL that references a remote file. First, you’re going to create a helper method to create this placeholder. Add the following to providePlaceholder(at:):

// 1
guard
  let identifier = persistentIdentifierForItem(at: url),
  let reference = MediaItemReference(itemIdentifier: identifier)
  else {
    throw FileProviderError.unableToFindMetadataForPlaceholder
}

// 2
try fileManager.createDirectory(
  at: url.deletingLastPathComponent(),
  withIntermediateDirectories: true,
  attributes: nil
)

// 3
let placeholderURL = NSFileProviderManager.placeholderURL(for: url)
let item = FileProviderItem(reference: reference)

// 4
try NSFileProviderManager.writePlaceholder(
  at: placeholderURL,
  withMetadata: item
)

Here is what’s going on:

  1. First, you create an identifier and a reference from the provided URL. If that fails, throw an error.
  2. When creating placeholders, you must ensure the enclosing directory exists or else you’ll run into problems. So, use NSFileManager to do so.
  3. The url passed into this method is for the image to be displayed, not the placeholder. So you create a placeholder URL with placeholderURL(for:) and obtain the NSFileProviderItem that this placeholder will represent.
  4. Write the placeholder item to the file system.

Next, replace the contents of providePlaceholder(at:completionHandler:) with the following:

do {
  try providePlaceholder(at: url)
  completionHandler(nil)
} catch {
  completionHandler(error)
}

The File Provider will call providePlaceholder(at:completionHandler:) when it requires a placeholder URL. In it, you attempt to create a placeholder with the helper you built above, and if there’s an error, you pass it to the completionHandler. On success, you don’t need to pass anything – the File Provider just expects you to write the placeholder URL, as you did in providePlaceholder(at:).

As a user navigates directories, the File Provider will call enumerator(for:) to ask for a FileProviderEnumerator for a given identifier. Replace the contents of this stubbed out method with the following:

if containerItemIdentifier == .rootContainer {
  return FileProviderEnumerator(path: "/")
}

guard
  let ref = MediaItemReference(itemIdentifier: containerItemIdentifier),
  ref.isDirectory
  else {
    throw FileProviderError.notAContainer
}

return FileProviderEnumerator(path: ref.path)

This method ensures that the item for the supplied identifier is a directory. If the identifier is the root item an enumerator is still created since the root is a valid directory.

Build and run. After the app gets launched, switch to the Files app and enable the app’s extension. Tap the Browse tab bar item twice to navigate to the root of Files. Select More Locations and toggle Provider, which is the name of the extension.

Note: If you couldn’t find Provider listed under More Locations, tap the Edit button in the top right corner to ensure that the disabled extensions show in the list.

First look at the extension.

You now have a working File Provider extension! There are a few important things missing, but you’ll add those next.

Providing Thumbnails

Since this app should show images from the back end, it’s important to show thumbnails for the images. There is a single method to override that will take care of thumbnail generation for the extension.

Add the following below enumerator(for:):

// MARK: - Thumbnails

override func fetchThumbnails(
  for itemIdentifiers: [NSFileProviderItemIdentifier],
  requestedSize size: CGSize,
  perThumbnailCompletionHandler:
    @escaping (NSFileProviderItemIdentifier, Data?, Error?) -> Void,
  completionHandler: @escaping (Error?) -> Void)
    -> Progress {
  // 1
  let progress = Progress(totalUnitCount: Int64(itemIdentifiers.count))

  for itemIdentifier in itemIdentifiers {
    // 2
    let itemCompletion: (Data?, Error?) -> Void = { data, error in
      perThumbnailCompletionHandler(itemIdentifier, data, error)

      if progress.isFinished {
        DispatchQueue.main.async {
          completionHandler(nil)
        }
      }
    }

    guard
      let reference = MediaItemReference(itemIdentifier: itemIdentifier),
      !reference.isDirectory
      else {
        progress.completedUnitCount += 1

        let error = NSError.fileProviderErrorForNonExistentItem(
          withIdentifier: itemIdentifier
        )
        itemCompletion(nil, error)
        continue
    }

    let name = reference.filename
    let path = reference.containingDirectory

    // 3
    let task = NetworkClient.shared
      .downloadMediaItem(named: name, at: path) { url, error in
        guard
          let url = url,
          let data = try? Data(contentsOf: url, options: .alwaysMapped)
          else {
            itemCompletion(nil, error)
            return
        }
        itemCompletion(data, nil)
    }

    // 4
    progress.addChild(task.progress, withPendingUnitCount: 1)
  }

  return progress
}

While this method is quite lengthy, its logic is simple:

  1. This method returns a Progress object that tracks the state of each thumbnail request.
  2. It defines a completion block for each itemIdentifier. The block will take care of calling each per item block required by this method as well as calling the final block at the end.
  3. The thumbnail file gets downloaded from the server to a temporary file using the NetworkClient included with the starter project. When the download completes, the completion handler passes the downloaded data to the itemCompletion closure.
  4. Each download task gets added as a dependency to the parent progress object.
Note: Making an individual network request for each placeholder might take some time when working with larger data sets. So if possible, your back end integration should provide a way to batch download images in a single request.

Build and run. Open the extension in Files and you should see thumbnails load in.

The thumbnails are now working.

Viewing Items

Right now when you select an item the app presents a blank view without the full image:

No content.

So far, you’ve only implemented the display of preview thumbnails — now it’s time to add the ability to view the full content!

Like the thumbnail generation, there is only a single method needed to view an item’s content and that is startProvidingItem(at:completionHandler:). Add the following to the bottom of the FileProviderExtension class:

// MARK: - Providing Items

override func startProvidingItem(
  at url: URL,
  completionHandler: @escaping ((_ error: Error?) -> Void)) {
  // 1
  guard !fileManager.fileExists(atPath: url.path) else {
    completionHandler(nil)
    return
  }

  // 2
  guard
    let identifier = persistentIdentifierForItem(at: url),
    let reference = MediaItemReference(itemIdentifier: identifier)
    else {
      completionHandler(FileProviderError.unableToFindMetadataForItem)
      return
  }

  // 3
  let name = reference.filename
  let path = reference.containingDirectory
  NetworkClient.shared
    .downloadMediaItem(named: name, at: path, isPreview: false) { fileURL, error in
    // 4
    guard let fileURL = fileURL else {
      completionHandler(error)
      return
    }

    // 5
    do {
      try self.fileManager.moveItem(at: fileURL, to: url)
      completionHandler(nil)
    } catch {
      completionHandler(error)
    }
  }
}

Here’s what this code does:

  1. Checks if an item already exists at the specified URL to prevent requesting the same data again. In a real world case use, you should check modification dates and file versions to be sure that you have the latest data. However, there is no need to do that in this tutorial since it doesn’t support versioning.
  2. Obtains the MediaItemReference for the associated URL so you know which file you need to fetch from the back end.
  3. Extracts the name and path from the reference to request the file contents from the back end.
  4. Fails if there was an error downloading the file.
  5. Moves the file from its temporary download directory into the document storage URL specified by the extension.

Build and run. After opening the extension, select an item to view the full version.

A full image is loaded.

As you open more files the extension will need to handle the removal of the downloaded files. The File Provider extension has this feature built in.

You must override stopProvidingItem(at:) to clean up the file as well as provide a new placeholder for it. Add the following at the bottom of the FileProviderExtension class:

override func stopProvidingItem(at url: URL) {
  try? fileManager.removeItem(at: url)
  try? providePlaceholder(at: url)
}

This removes the item, and calls providePlaceholder(at:) to generate a new placeholder.

That completes the most basic functionality of the File Provider. File enumeration, thumbnail previews, and viewing the file content are the essential components of this extension.

Congratulations, the File Provider is complete and functional!

Where to Go From Here?

You now have an app with a working File Provider extension. The extension can enumerate and view items from a back end.

You can download the completed version of the project using the Download Materials button at the top or bottom of this tutorial.

Learn about more actions you can implement for your File Provider in Apple’s Documentation about File Providers. You can also add custom UI to the File Provider using another extension and you can read more about that here.

Checkout this tutorial on Document-Based Apps if you’re interested in more ways to work with files on iOS.

I hope you enjoyed this tutorial! If you have any questions or comments, please join the discussion below.

Average Rating

5/5

Add a rating for this content

3 ratings

Contributors

Comments
