Swift Tutorial Part 3: Flow Control

Welcome to part 3 of our Swift tutorial, where you’ll learn how code decisions using Booleans and repeat tasks using loops to control the flow.

5/5 13 Ratings

Version

  • Swift 4.2, iOS 12, Xcode 10
Update note: Lorenzo Boaro updated this tutorial to iOS 12, Xcode 10, and Swift 4.2. Matt Galloway wrote the original.

Welcome to the final part of this Swift mini-series! If you haven’t read through Part 1 or Part 2 of this series, we suggest you do that first.

In computer programming terms, the ability to tell the computer what to do in different scenarios is known as control flow.

In this tutorial, you’ll learn how to make decisions and repeat tasks in your programs by using syntax to control the flow. You’ll also learn about Booleans, which represent true and false values, and how you can use these to compare data.

Getting Started

At this point, you’ve seen a few types, such as Int, Double and String. Here, you’ll learn about another type — one that will let you compare values through the comparison operators.

When you perform a comparison, such as looking for the greater of two numbers, the answer is either true or false. Swift has a data type just for this! It’s called Bool, which is short for Boolean, after George Boole who invented an entire field of mathematics around the concept of true and false.

This is how you use a Boolean in Swift:

let yes = true // Inferred to be of type Bool
let no = false // Inferred to be of type Bool

A Boolean can only be either true or false, denoted by the keywords true and false. In the code above, you use the keywords to set the value of each constant.

Boolean Operators

Booleans are commonly used to compare values. For example, you may have two values and you want to know if they’re equal: Either the values are the same (true) or they are different (false).

In Swift, you do this using the equality operator, which is denoted by ==:

let doesOneEqualTwo = (1 == 2)

Swift infers that doesOneEqualTwo is a Bool. Clearly, 1 does not equal 2, and therefore doesOneEqualTwo will be false.

Similarly, you can find out if two values are not equal using the != operator:

let doesOneNotEqualTwo = (1 != 2)

This time, the comparison is true because 1 does not equal 2, so doesOneNotEqualTwo will be true.

The prefix ! operator, also called the not operator, toggles true to false and false to true. Another way to write the above is:

let alsoTrue = !(1 == 2)

Evaluating this step by step: 1 does not equal 2, so (1==2) is false, and then ! toggles false to true.

Two more operators let you determine if a value is greater than (>) or less than (<) another value. You’ll likely know these from mathematics:

let isOneGreaterThanTwo = (1 > 2)
let isOneLessThanTwo = (1 < 2)

It’s not rocket science to work out that isOneGreaterThanTwo will equal false and isOneLessThanTwo will equal true.

There’s also an operator that lets you test if a value is less than or equal to another value: <=. It’s a combination of < and ==, and will therefore return true if the first value is either less than the second value or equal to it.

Similarly, >= operator lets you test if a value is greater than or equal to another.

Boolean Logic

The examples above test just one condition. In order to combine multiple conditions to form a result, you can rely on Boolean logic.

One way to combine conditions is by using AND. When you AND together two Booleans, the result is another Boolean. If both input Booleans are true, then the result is true. Otherwise, the result is false.

george_boole

In Swift, the operator for Boolean AND is &&, used like so:

let and = true && true

In this case, and will be true. If either of the values on the right was false, then and would be false.

Another way to combine conditions is by using OR. When you OR together two Booleans, the result is true if either of the input Booleans is true. Only if both input Booleans are false will the result be false.

In Swift, the operator for Boolean OR is ||, used like so:

let or = true || false

In this case, or will be true. If both values on the right were false, then or would be false. If both were true, then or would still be true.

In Swift, Boolean logic is usually applied to multiple conditions. For example, consider the following:

let andTrue = 1 < 2 && 4 > 3
let andFalse = 1 < 2 && 3 > 4

let orTrue = 1 < 2 || 3 > 4
let orFalse = 1 == 2 || 3 == 4

Each of these tests two separate conditions, combining them with either AND or OR.

It’s also possible to use Boolean logic to combine more than two comparisons. For example, you can form a complex comparison like so:

let andOr = (1 < 2 && 3 > 4) || 1 < 4

When you include parentheses around part of the expression, you specify the order of evaluation. First, Swift evaluates the sub-expression inside the parentheses, and then it evaluates the full expression, as follows:

1. (1 < 2 && 3 > 4) || 1 < 4
2. (true && false) || true
3. false || true
4. true

String Equality

Sometimes, you want to determine if two strings are equal. For example, a children’s game of naming an animal in a photo would need to determine if the player answered correctly.

In Swift, you can compare strings using the standard equality operator, ==, in exactly the same way as you compare numbers. For example:

let guess = "dog"
let dogEqualsCat = guess == "cat"

dogEqualsCat is a Boolean that in this case equals false, because "dog" does not equal "cat".

Just as with numbers, you can compare not just for equality, but also to determine is one value is greater than or less that another value. For example:

let order = "cat" < "dog"

This syntax checks if one string comes before another alphabetically. In this case, order equals true because "cat" comes before "dog".

The if Statement

The first and most common way of controlling the flow of a program is through the use of an if statement, which allows the program to do something only if a certain condition evaluates as true. For example, consider the following:

if 2 > 1 {
  print("Yes, 2 is greater than 1.")
}

This is a simple if statement. If the condition is true, then the statement will execute the code between the braces. If the condition evaluates to false, then the statement won’t execute the code between the braces.

You can extend an if statement to provide code to run in case the condition turns out to be false. This is known as the else clause. For example:

let animal = "Fox"
if animal == "Cat" || animal == "Dog" {
  print("Animal is a house pet.")
} else {
  print("Animal is not a house pet.")
}

Here, if animal equals either "Cat" or "Dog", then the statement will run the first block of code. If animal does not equal either "Cat" or "Dog", then the statement will run the block inside the else part of the if statement, printing the following to the debug area:

Animal is not a house pet.

But you can go even further than that with if statements. Sometimes, you want to check one condition, then another. This is where else-if comes into play, nesting another if statement in the else clause of a previous if statement.

You can use it like so:

let hourOfDay = 12
var timeOfDay = ""

if hourOfDay < 6 {
  timeOfDay = "Early morning"
} else if hourOfDay < 12 {
  timeOfDay = "Morning"
} else if hourOfDay < 17 {
  timeOfDay = "Afternoon"
} else if hourOfDay < 20 {
  timeOfDay = "Evening"
} else if hourOfDay < 24 {
  timeOfDay = "Late evening"
} else {
  timeOfDay = "INVALID HOUR!"
}
print(timeOfDay)

These nested if statements test multiple conditions one-by-one until a true condition is found. Only the code associated with that first true condition is executed, regardless of whether subsequent else-if conditions are true. In other words, the order of your conditions matters!

You can add an else clause at the end to handle the case in which none of the conditions are true. This else clause is optional if you don’t need it; in this example, you do need it to ensure that timeOfDay has a valid value by the time you print it out.

In this example, the if statement takes a number representing an hour of the day and converts it to a string that represents the part of the day to which the hour belongs. Working with a 24-hour clock, the statements are checked one-by-one in order.

In the code above, the hourOfDay constant is 12. Therefore, the code will print the following:

Afternoon

Notice that, even though both the hourOfDay < 20 and hourOfDay < 24 conditions are also true, the statement only executes the first block whose condition is true; in this case, the block with the hourOfDay < 17 condition.

Encapsulating Variables

if statements introduce a new concept scope, which is a way to encapsulate variables through the use of braces.

Imagine that you want to calculate the fee to charge your client. Here’s the deal you’ve made:

You earn $25 for every hour up to 40 hours, and $50 for every hour thereafter.

Using Swift, you can calculate your fee in this way:

var hoursWorked = 45

var price = 0
if hoursWorked > 40 {
  let hoursOver40 = hoursWorked - 40
  price += hoursOver40 * 50
  hoursWorked -= hoursOver40
}
price += hoursWorked * 25

print(price)

This code takes the number of hours and checks if it’s over 40. If so, the code calculates the number of hours over 40 and multiplies that by $50, then adds the result to the price. The code then subtracts the number of hours over 40 from the hours worked. It multiplies the remaining hours worked by $25 and adds that to the total price.

In the example above, the result is as follows:

1250

hoursOver40 declares a new constant that you can use inside the if statement. But what happens if you try to use it at the end of the above code?

// ...

print(price)
print(hoursOver40)

This would result in the following error:

Use of unresolved identifier 'hoursOver40'

This error informs you that you’re only allowed to use the hoursOver40 constant within the scope in which it was created. In this case, the if statement introduced a new scope, so when that scope is finished, you can no longer use the constant.

However, each scope can use variables and constants from its parent scope. In the example above, the scope inside of the if statement uses the price and hoursWorked variables, which you created in the parent scope.

The Ternary Conditional Operator

The ternary conditional operator takes a condition and returns one of two values, depending on whether the condition was true or false. The syntax is as follows:

(<CONDITION>) ? <TRUE VALUE> : <FALSE VALUE>

Here's an example that tests the minimum of two variables:

let a = 5
let b = 10

let min: Int
if a < b {
  min = a
} else {
  min = b
}

Thanks to the ternary operator, you can rewrite your code above like so:

let a = 5
let b = 10

let min = a < b ? a : b

If the condition a < b is true, then the result assigned back to min will be the value of a; if it’s false, the result will be the value of b.

Note: Use ternary operator with care. Its conciseness can lead to hard-to-read code if overused.

Loops

Loops are a way of executing code multiple times. In this section, you’ll learn about the while loop.

While Loops

A while loop repeats a block of code while a condition is true.

You create a while loop this way:

while <CONDITION> {
  <LOOP CODE>
}

During every iteration, the loop checks the condition. If the condition is true, then the loop executes and moves on to another iteration. If the condition is false, then the loop stops. Just like if statements, while loops introduce a scope.

The simplest while loop takes this form:

while true {
}

This is a while loop that never ends because the condition is always true. An infinite loop might not cause your program to crash, but it will very likely cause your computer to freeze.

Force quit

Here’s a more useful example of a while loop:

var sum = 1

while sum < 1000 {
  sum = sum + (sum + 1)
}

This code calculates a mathematical sequence, up to the point in which the value is greater than 1000.

The loop executes as follows:

While Loop iteration

After the ninth iteration, the sum variable is 1023 and, therefore, the loop condition of sum < 1000 becomes false. At this point, the loop stops.

Repeat-while Loops

A variant of the while loop is called the repeat-while loop. It differs from the while loop in that the condition is evaluated at the end of the loop rather than at the beginning.

You construct a repeat-while loop like this:

repeat {
  <LOOP CODE>
} while <CONDITION>

Here’s the example from the last section, but using a repeat-while loop:

sum = 1

repeat {
  sum = sum + (sum + 1)
} while sum < 1000

In this example, the outcome is the same as before. However, that isn’t always the case — you might get a different result with a different condition.

Consider the following while loop:

sum = 1

while sum < 1 {
  sum = sum + (sum + 1)
}

And now consider the corresponding repeat-while loop, which uses the same condition:

sum = 1

repeat {
  sum = sum + (sum + 1)
} while sum < 1

In the case of the regular while loop, the condition sum < 1 is false right from the start. That means the body of the loop won’t be reached! The value of sum will equal 1 because the loop won’t execute any iterations.

In the case of the repeat-while loop, however, sum will equal 3 because the loop will execute once.

Breaking Out of a Loop

Sometimes you want to break out of a loop early. You can do this using the break statement, which immediately stops the execution of the loop and continues on to the code after the loop.

For example, consider the following code:

sum = 1

while true {
  sum = sum + (sum + 1)
  if sum >= 1000 {
    break
  }
}

Here, the loop condition is true, so the loop would normally iterate forever. However, the break means the while loop will exit once the sum is greater than or equal to 1000.

Advanced Control Flow

In this section, you’ll continue to learn how to control the flow of execution. You’ll learn about another loop known as the for loop.

Ranges

Before you dive into the for loop statement, you need to know about the ClosedRange and Range types, which lets you represent a sequence of numbers.

First, there’s closed range, which you represent like so:

let closedRange = 0...5

The three dots (...) indicate that this range is closed, which means the range goes from 0 to 5, inclusive. That means the numbers (0, 1, 2, 3, 4, 5).

Second, there’s half-open range, which you represent like so:

let halfOpenRange = 0..<5

Here, you replace the three dots with two dots and a less-than sign (..<). Half open means the range goes from 0 to 5, inclusive of 0 but not of 5. That means the numbers (0, 1, 2, 3, 4).

Both closed and half-open ranges must always be increasing. In other words, the second number must always be greater than or equal to the first.

Ranges are commonly used in both for loops and switch statements, which means you’ll use ranges soon!

For Loops

Now that you know about ranges, it’s time to look at the for loop. It's used to run code a certain number of times.

You construct a for loop like this:

for <CONSTANT> in <RANGE> {
  <LOOP CODE>
}

The loop begins with the for keyword, followed by a name given to the loop constant, followed by in, followed by the range to loop through.

Here’s an example:

let count = 10
var sum = 0

for i in 1...count {
  sum += i
}

The for loop iterates through the range 1 to count. At the first iteration of the loop, i will equal the first element in the range — 1. Each time around the loop, i will increment until it’s equal to count; the loop will execute one final time and then finish.

Note: If you’d used a half-open range, then the last iteration would see i equal to count - 1.

Inside the loop, you add i to the sum variable; it runs 10 times to calculate the sequence 1 + 2 + 3 + 4 + 5 + ... all the way up to 10.

Here are the values of the constant i and variable sum for each iteration:

For Loop iteration

The i constant is only visible inside the scope of the for loop, which means it’s not available outside of the loop.

When you are not interested in the loop constant at all, you can employ the underscore to indicate that you’re ignoring it. For example:

sum = 1
var lastSum = 0

for _ in 0..<count {
  let temp = sum
  sum = sum + lastSum
  lastSum = temp
}

This code doesn’t require a loop constant; the loop simply needs to run a certain number of times. In this case, the range is 0 through count and is half open. This is the usual way of writing loops that run a certain number of times.

It’s also possible to only perform the iteration under certain conditions. For example, imagine that you wanted to compute a sum but only for odd numbers:

var sum = 0
for i in 1...count where i % 2 == 1 {
  sum += i
}

The loop above has a where clause in the for loop statement. The loop still runs through all values in the range 1 to count, but it will only execute the loop’s code block when the where condition is true; in this case, it executes when i is odd.

Continue Statement

Sometimes you’d like to skip a loop iteration for a particular case without breaking out of the loop entirely. You can do this with the continue statement, which immediately ends the current iteration of the loop and starts the next iteration.

Note: Use continue statement instead of simpler where clause when you need a higher level of control.

Take the example of an 8 ✕ 8 grid, wherein each cell holds a value of the row multiplied by the column:

full_board

It looks much like a multiplication table, doesn’t it?

Let’s say you wanted to calculate the sum of all cells but exclude all even rows, as shown below:

first_board_example

Using a for loop, you can achieve this as follows:

sum = 0

for row in 0..<8 {
  if row % 2 == 0 {
    continue
  }

  for column in 0..<8 {
    sum += row * column
  }
}

When the row modulo 2 equals 0, the row is even. In this case, continue makes the for loop skip to the next row.

Just like break, continue works with both for loops and while loops.

Note: Swift also provides labeled statements as location specifiers for continue and break in flow control elements. If you want to learn more, read our book Swift Apprentice, Fourth Edition.

Switch Statements

Another way to control flow is through the use of a switch statement, which lets you execute different bits of code depending on the value of a variable or constant.

Here’s a very simple switch statement that acts on an integer:

let number = 10

switch number {
case 0:
  print("Zero")
default:
  print("Non-zero")
}

The code will print the following:

Non-zero

The purpose of this switch statement is to determine whether or not a number is zero.

To handle a specific case, you use case, followed by the value that you want to check for, which, in this case, is 0. Then, you use default to signify what should happen for all other values.

Here’s another example:

switch number {
case 10:
  print("It's ten!")
default:
  break
}

This time you check for 10, in which case, you print a message. Nothing should happen for other values. When you want nothing to happen for a case, or you want the default state to run, you use the break statement. This tells Swift that you meant to not write any code here and that nothing should happen. Cases can never be empty, so you must write some code, even if it’s just a break!

switch statements work with any data type! Here’s an example of switching on a string:

let string = "Dog"

switch string {
case "Cat", "Dog":
  print("Animal is a house pet.")
default:
  print("Animal is not a house pet.")
}

This will print the following:

Animal is a house pet.

In this example, you provide two values for the case, meaning that if the value is equal to either "Cat" or "Dog" then the statement will execute the case.

Advanced Switch Statements

You can also give your switch statements more than one case. In the previous section, you saw an if statement using multiple else-if statements to convert an hour of the day to a string describing that part of the day. You could rewrite that more succinctly with a switch statement, like so:

let hourOfDay = 12
var timeOfDay = ""

switch hourOfDay {
case 0, 1, 2, 3, 4, 5:
  timeOfDay = "Early morning"
case 6, 7, 8, 9, 10, 11:
  timeOfDay = "Morning"
case 12, 13, 14, 15, 16:
  timeOfDay = "Afternoon"
case 17, 18, 19:
  timeOfDay = "Evening"
case 20, 21, 22, 23:
  timeOfDay = "Late evening"
default:
  timeOfDay = "INVALID HOUR!"
}

print(timeOfDay)

This code will print the following:

Afternoon

Remember ranges? Well, you can use ranges to simplify this switch statement. You can rewrite it in a more succinct and clearer way using ranges as shown below:

var timeOfDay2 = ""

switch hourOfDay {
case 0...5:
  timeOfDay2 = "Early morning"
case 6...11:
  timeOfDay2 = "Morning"
case 12...16:
  timeOfDay2 = "Afternoon"
case 17...19:
  timeOfDay2 = "Evening"
case 20..<24:
  timeOfDay2 = "Late evening"
default:
  timeOfDay2 = "INVALID HOUR!"
}

print(timeOfDay2)

It’s also possible to match a case to a condition based on a property of the value. As you learned in the first part of this tutorial series, you can use the modulo operator to determine if an integer is even or odd. Consider this code:

switch number {
case let x where x % 2 == 0:
  print("Even")
default:
  print("Odd")
}

This will print the following:

Even

This switch statement uses the let-where syntax, meaning the case will match only when a certain condition is true. The let part binds a value to a name, while the where part provides a Boolean condition that must be true for the case to match. In this example, you’ve designed the case to match if the value is even — that is, if the value modulo 2 equals 0.

The method by which you can match values based on conditions is known as pattern matching.

In the previous example, the binding introduced an unnecessary constant x; it’s simply another name for number. You are allowed to use number in the where clause and replace the binding with an underscore to ignore it:

switch number {
case _ where number % 2 == 0:
  print("Even")
default:
  print("Odd")
}

Partial Matching

Another way you can use switch statements with matching to great effect is as follows:

let coordinates = (x: 3, y: 2, z: 5)

switch coordinates {
case (0, 0, 0): // 1
  print("Origin")
case (_, 0, 0): // 2
  print("On the x-axis.")
case (0, _, 0): // 3
  print("On the y-axis.")
case (0, 0, _): // 4
  print("On the z-axis.")
default:        // 5
  print("Somewhere in space")
}

This switch statement makes use of partial matching. Here’s what each case does, in order:

  1. Matches precisely the case in which the value is (0, 0, 0). This is the origin of 3D space.
  2. Matches y=0, z=0 and any value of x. This means the coordinate is on the x-axis.
  3. Matches x=0, z=0 and any value of y. This means the coordinate is on the y-axis.
  4. Matches x=0, y=0 and any value of z. This means the coordinate is on the z-axis.
  5. Matches the remainder of coordinates.

You’re using the underscore to mean that you don’t care about the value. If you don’t want to ignore the value, then you can bind it and use it in your switch statement, like this:

switch coordinates {
case (0, 0, 0):
  print("Origin")
case (let x, 0, 0):
  print("On the x-axis at x = \(x)")
case (0, let y, 0):
  print("On the y-axis at y = \(y)")
case (0, 0, let z):
  print("On the z-axis at z = \(z)")
case let (x, y, z):
  print("Somewhere in space at x = \(x), y = \(y), z = \(z)")
}

Here, the axis cases use the let syntax to pull out the pertinent values. The code then prints the values using string interpolation to build the string.

Notice how you don’t need a default in this switch statement. This is because the final case is essentially the default; it matches anything, because there are no constraints on any part of the tuple. If the switch statement exhausts all possible values with its cases, then no default is necessary.

Also notice how you could use a single let to bind all values of the tuple: let (x, y, z) is the same as (let x, let y, let z).

Finally, you can use the same let-where syntax that you saw earlier to match more complex cases. For example:

switch coordinates {
case let (x, y, _) where y == x:
  print("Along the y = x line.")
case let (x, y, _) where y == x * x:
  print("Along the y = x^2 line.")
default:
  break
}

Here, you match the “y equals x” and “y equals x squared” lines.

Where to Go From Here?

You can download the final playground using the Download Materials button at the top or bottom of this tutorial. To improve your Swift skills, you will find some mini-exercises to complete. If you are stuck or you need some help, feel free to take advantage of companion solutions.

You’ve learned a lot about the core language features for dealing with data over these past few tutorials — from data types to variables, then on to decision making with Booleans and loops with ranges.

If you have any questions or comments, please tell us in the discussion below!

swift-apprentice

This tutorial was taken from Chapters 4 and 5 of Swift Apprentice, Fourth Edition, available from the raywenderlich.com store.

Check it out and let us know what you think!

Average Rating

5/5

Add a rating for this content

13 ratings

More like this

Contributors

Comments
